Fiat Palio Uno Fiasa Head with Valves 1.0 1.3 1.5 8v

Nº do produto.

ML Nº.	Nº OEM.	Nº DE REF.
MLG099A	46413809
MLG099B	7110142
MLG099C

Fiat Uno Palio 1.0 1.3 1.5 cylinder head complete with valves OEM-style head for Fiat 1.5 8V engine FIASA Brazil Fully assembled aluminum head for Fiat Elba Premio Fiorino Fiat FIASA engine head compatible with MPI and carbureted intake Complete cylinder head kit for Fiat FIASA 1.3 engine Latin America

Informações sobre o produto Cabeçote do cilindro

SOHC | 8-Valve | MPI / Carbureted | Cast Iron Block | Petrol

1. Visão geral do produto

This cylinder head fits FIASA (Fiat Automóveis S.A.) 8-valve petrol engines, widely used in Fiat models like Uno, Palio, Elba, Premio, and Fiorino, primarily in Latin America. These SOHC heads are known for their simplicity, durability, e mechanical reliability in daily-use compact vehicles.

FIASA engines are different from the later FIRE series. These heads are not interchangeable with FIRE engines.

2. Especificações Técnicas

Item	Detalhe
Família de motores	FIASA (Fiat Automóveis S.A.)
Displacement Compatibility	1.0L / 1.3L / 1.5L
Trem de válvulas	SOHC – 8 válvulas (2 por cilindro)
Material	Aluminum Cylinder Head, Cast Iron Block
Sistema de combustível	MPI (Multi-point Injection) or Carbureted
Combustion Chamber Type	Wedge type, depending on compression ratio
Sistema de refrigeração	Refrigerado a água
Spark Plug Configuration	Central or side-fire (depending on version)

3. OEM Reference Numbers (Exemplos)

Número da peça	Descrição
71716314	Complete head with valves for 1.5 MPI
46413809	Cylinder head for 1.0/1.3 carbureted engine
7110142	Bare head for 1.5 engine

Actual part numbers vary by fuel system, emissions spec, and valve guide diameter.

4. Aplicações de veículos compatíveis

Modelo	Anos	Notas
Fiat Uno	1984–2004	1.0 / 1.3 / 1.5 FIASA engines
Fiat Palio	1996–2001	1.0 / 1.5 MPI or carbureted
Fiat Elba	1986–1996	1.3 / 1.5 engines
Fiat Fiorino	1988–2000	1.3 / 1.5 carbureted / MPI
Fiat Premio	1985–1992	1.3 / 1.5 SOHC

Amplamente utilizado em Brazil, Argentina, Chile, Uruguay, and other LATAM markets.

5. Características do produto

Inclui pre-installed valves, springs, and retainers
Manufactured from high-grade aluminum alloy for heat resistance
Supports both carbureted and MPI intake manifolds
Compatível com mechanical or hydraulic lifters, depending on model
Machined surfaces for OEM fitment and sealing

6. Common Issues & Maintenance Advice

Problema	Causa provável	Recommended Solution
Cabeçote de cilindro empenado	Overheating or blown gasket	Reaproveitar ou substituir
Erosão da sede da válvula	Poor fuel or high mileage	Regrind or install new seats
Tappet noise	Improper lash or worn lifters	Adjust or replace components
Oil/coolant mixing	Cracked head or bad gasket	Replace head or gasket

7. Diretrizes de instalação

Usar new head bolts and head gasket
Torque para OEM sequence and spec
Verificar valve lash settings (if mechanical)
Verificar manifold compatibility (MPI vs. carbureted)
Flush cooling system after head replacement

Deslocamento	Combustível	Cilindro	Vale	Eixo de comando	Ano
1.0 / 1.3 / 1.5	Gasolina	4	8	1
