Applicable Engine:
K4M NEW / K4M OLD / L90
Applicable Brand:
RENAULT
Applicable Car:
RENAULT/LONDAR
Product parameters:
| Displacement | Fuel | Cylinder | Vale | Camshaft | Year |
| 1.6 | Gasoline | 4 | 16 | 2 | 2000- |
Cylinder Head
Cylinder Head for Renault K4M L90 Engine
Introduction
Product NO.
| ML NO. | OEM NO. | REF NO. |
| MLG114 | 7701473353 7701471364 7700600530 8200843474F | |
| MLG208 | 7701474364 7701474361 7701475914 7701472123 |
Product 1: Cylinder Head for Renault K4M L90 OLD Engine
Product Title
High-Quality Aluminum Cylinder Head for Renault K4M L90 1.6 16V Engine (OLD Type)
Applications
- Renault Logan / Dacia Logan L90 1.6 16V
- Renault Megane I / II 1.6 16V
- Renault Clio II 1.6 16V
- Renault Symbol 1.6 16V
- Renault Scenic 1.6 16V
- Engine Code: K4M OLD Type (Without VVT)
OEM / Part Numbers
- 7701471364
- 7701473352
- 7701473353
- 7701474361
- 7701475914
(Equivalent and interchange numbers available upon request.)
Technical Specifications
| Item | Specification |
|---|---|
| Engine Type | 1.6 L 16 Valve DOHC Petrol Engine |
| Bore × Stroke | 79.5 mm × 80.5 mm |
| Cylinder Head Material | Aluminum Alloy |
| Valve Train | Double Overhead Camshaft (DOHC) |
| Valves per Cylinder | 4 (16 Valves Total) |
| Camshaft Control | Fixed Cam Timing (No VVT) |
| Compression Ratio | 9.5 – 9.8 : 1 |
| Fuel System | Multipoint Fuel Injection (MPFI) |
Product Features
- Precision machined aluminum casting for optimal heat dissipation.
- Suitable for early Renault K4M L90 engines without variable valve timing (VVT).
- High durability under continuous operation and high temperature conditions.
- 100% pressure-tested for coolant and oil tightness before shipment.
- Compatible with original gasket sets and camshaft assemblies.
Common Faults & Maintenance Tips
- Overheating due to coolant leak or poor radiator performance may cause head warpage.
- Valve seat burning or cracks can occur if ignition timing is incorrect.
- Regularly check the coolant system and replace the head gasket if oil and water mixing is detected.
SEO Keywords
Renault K4M Cylinder Head, Renault L90 1.6 Head, Dacia Logan K4M Head, K4M Old Type Head, Renault 16V Cylinder Head, Renault Megane K4M Head, OEM 7701471364 Head
Product 2: Cylinder Head for Renault K4M NEW Engine (with VVT)
Product Title
Brand-New Cylinder Head for Renault K4M 1.6 16V VVT Engine (New Type)
Applications
- Renault Megane II / III 1.6 16V
- Renault Scenic II / III 1.6 16V
- Renault Fluence 1.6 16V
- Dacia Logan / Sandero 1.6 16V (VVT Type)
- Engine Code: K4M NEW Type (With Variable Valve Timing)
OEM / Part Numbers
- 7701475915
- 7701477385
- 110411306R
- 110411305R
- (Replacement for earlier 7701471364 series with VVT modification)
Technical Specifications
| Item | Specification |
|---|---|
| Engine Type | 1.6 L 16 Valve DOHC Petrol Engine (VVT Version) |
| Bore × Stroke | 79.5 mm × 80.5 mm |
| Cylinder Head Material | Aluminum Alloy |
| Valve Train | DOHC with Variable Valve Timing (VVT) |
| Valves per Cylinder | 4 (16 Valves Total) |
| Compression Ratio | Approx. 10.0 – 10.3 : 1 |
| Cooling | Water-cooled with improved flow channels |
| Fuel System | Sequential Multipoint Fuel Injection (SMPI) |
Product Features
- New design with VVT camshaft system for better fuel efficiency and torque.
- CNC-machined valve seats and guides for long service life.
- Upgraded cooling and oil circulation design compared to old L90 type.
- Fully assembled head available with valves and springs upon request.
- Each unit undergoes pressure leak test and surface flatness inspection.
Common Faults & Maintenance Tips
- Replace cam seals and VVT solenoid seals during installation.
- Always use new head bolts and OEM-grade gasket to ensure tightness.
- Check timing belt and VVT actuator function after head assembly.
Packaging & Quality Assurance
- Neutral or Customized Packing Available.
- Each Head Individually Packed in Protective Foam and Strong Carton.
- 100% Leak Test and Pressure Check Before Shipping.
- Warranty: 12 Months Against Manufacturing Defects.
